SCC-48-100-S

Core Benefits (Vertical Home Energy Storage, Integrated Housing, IP20 Protection):

· Dimension:400*152*590mm (wheel-free)

· Weight: About 45kg

· Integrated 5.0 Bluetooth Low Energy & WiFi

· Class A prismatic LiFePO4 cells

· Complete unit IP20 rated

· Max. Continuous Charge/Discharge Current: 100A

· Supports max. 16 units in parallel via RS485

· Perfect for Solar Household Off-Grid Energy Storage Applications

· 7-inch Touch Display Screen

· Communication: Bluetooth / WiFi / CAN / RS232 / RS485

· Cycle Life: ≥4000 cycles @DOD70%, 25℃

· 5-year Manufacturer's Warranty

Product Overview

This vertical home energy storage battery adopts Grade A LiFePO4 prismatic cells, equipped with an intelligent built-in BMS and 7-inch touch display. It supports up to 16 unit parallel connection via RS485 and is compatible with most mainstream solar inverters. With multi channel communication including Bluetooth, WiFi, CAN and RS485, you can easily monitor battery status via mobile APP. Ideal for off-grid solar household systems to maximize solar self-consumption.

上一产品：SCC-48-300-S

下一产品：SCC-48-200-S

描述

SCC48100S -- FEATURES

Compared with traditional lead-acid batteries, this vertical LiFePO4 home energy storage battery brings multiple outstanding advantages:

• 5-year manufacturer's warranty for reliable long-term operation

• Safe LiFePO4 chemistry with comprehensive BMS protection to reduce fire & explosion risks

• Grade-A prismatic energy-storage cells, ≥4000 cycles @ DOD70%, 25℃

• Built-in intelligent BMS with full protections: over-charge, over-discharge, over-current, short-circuit & over-temperature

• Supports up to 16-unit parallel connection via RS485 for flexible capacity expansion

• Compatible with most mainstream energy-storage inverters, ideal for off-grid household solar storage

• 7-inch high-definition touch screen for local real-time battery data display

• Multiple communication ports: Bluetooth 5.0, WiFi, CAN, RS232, RS485

• No memory effect; no mandatory full charge-discharge maintenance cycles

• Wide operating-temperature range for diverse environmental conditions

• High-efficiency deep charge & discharge to maximize solar self-consumption

Integrated Bluetooth 5.0 & WiFi Intelligent Monitoring

• Access critical battery data including SOC, voltage, current and temperature anytime via smartphone or tablet APP.

• Real-time status refresh on mobile APP for convenient remote monitoring.

【Attention】

Please charge the battery before first-time use upon receipt. For transportation safety, the battery is shipped at approximately 30% state-of-charge. It may become fully depleted during transit. Please complete charging prior to commissioning.

【Important Notes】

• Do not expose the battery to direct sunlight. Keep away from heat sources.

• Keep the LiFePO4 battery dry and clean at all times.

• Avoid mechanical damage such as dropping, drilling or piercing (risk of short-circuit).

• Observe positive (+) and negative (-) polarity, ensure correct polarity connection.

• Ensure proper installation and assembly.

• Do not short-circuit the battery terminals.

• Do not disassemble the LiFePO4 battery without authorization from SUPCELION®.

SCC48100S--SPECIFICATIONS
